OBO BETTERMANN Rehau RAUDUO koppeling 40/105 RAL9010 RD Kup40105 rws (6132176)

In pre-insulated pipe systems for district heating, creating a durable, watertight joint between service pipe and casing is critical. The OBO BETTERMANN Rehau RAUDUO Coupling 40/105 solves this by providing a heat-shrinkable connection that seals the casing pipe to the service pipe, ensuring long-term integrity of the insulation. This coupling is specifically designed for Rehau RAUDUO systems with a 40 mm service pipe and 105 mm casing pipe, in RAL 9010 pure white.

Who is it for

Installers and contractors working on pre-insulated pipe networks, especially district heating and cooling systems, who need a reliable, watertight joint that withstands environmental stress. It is ideal for both new installations and repairs on Rehau RAUDUO pipes.

Main features

• Compatible with Rehau RAUDUO pre-insulated pipe system
• Fits 40 mm service pipe and 105 mm casing pipe
• Heat-shrinkable design for a secure, watertight seal
• HDPE casing material for durability and corrosion resistance
• Elastomer sealing for flexibility and long-term performance
• Colour: RAL 9010 (pure white)
• UV resistant for outdoor applications
• Maximum operating temperature: 95 °C
• Pressure rating: PN10

Specifications

• Product type: Coupling
• System compatibility: Rehau RAUDUO
• Service pipe diameter: 40 mm
• Casing pipe outer diameter: 105 mm
• Material (casing): High-density polyethylene (HDPE)
• Material (sealing): Elastomer
• Insulation compatibility: PUR (polyurethane) foam insulated pipes
• Water tightness: Yes
• UV resistance: Yes
• Maximum operating temperature: 95 °C
• Maximum operating pressure: PN10
• Installation method: Requires heat gun
• Corrosion resistance: Yes
• Chemical resistance: Good against common soil chemicals
• Standard compliance: EN 15632

Tips

Ensure the pipe surfaces are clean and dry before installation. Use a heat gun with appropriate temperature settings to shrink the coupling evenly, following the manufacturer's guidelines. For best results, verify that the pipe dimensions match the coupling size (40/105) before ordering.
