OBO Bettermann T100ED 06A aftakdoos 150x116x67mm lichtgrijs IP66 7205740

Protect electrical connections in damp or dusty environments with the OBO Bettermann T100ED 06A junction box. Its IP66-rated enclosure keeps out water jets and dust, while the halogen-free polypropylene body withstands impact and UV exposure for long-term reliability.

Who is it for

Electricians and installers who need a robust, tool-free junction box for indoor or outdoor protected installations, such as in industrial facilities, workshops, or external walls under canopies.

Main features

• Dimensions: 150 x 116 x 67 mm (W x H x D)
• Light grey (RAL 7035) polypropylene housing, halogen-free and UV-resistant
• IP66 protection against dust and powerful water jets
• Rated insulation voltage up to 690 V
• 8 integrated soft membrane cable entries for M25 cables
• Snap-on cover for quick, tool-free closing
• Internal mounting points for wall or ceiling installation
• Impact resistance IK07 and glow wire test at 750 °C
• Temperature range: -25 °C to +40 °C

Specifications

• Material: Polypropylene (PP)
• Colour: Light grey (RAL 7035)
• Protection class: IP66
• Rated insulation voltage: 690 V
• Halogen-free: Yes
• UV-resistant: Yes
• Temperature range: -25 to +40 °C
• Impact resistance: IK07
• Glow wire test: 750 °C
• Number of cable entries: 8 (for M25)
• Cover fastening: Snap-on (tool-free)
• Seal material: TPE
• Mounting type: Internal mounting points for wall/ceiling
• Flammability class: Self-extinguishing
• Internal depth: 58 mm
• Application: Indoor and outdoor protected installations

Tips

For outdoor use, mount the box in a location sheltered from direct sunlight and extreme weather to extend its service life. Ensure cables are properly sealed in the soft membranes to maintain the IP66 rating.
