PATRIOT Signature Line - DDR4 - module - 16 GB

The Patriot Memory DDR4 16GB 2666MHz module provides mainstream desktop and server systems with reliable DRAM performance. This 288-pin DIMM operates at 2666 MHz with CAS latency 19 and 1.2 V, offering a single-module 16 GB capacity suitable for multitasking and demanding applications. The module comes in a black and green design and is intended as a straightforward plug-and-play memory upgrade for compatible PC builds.

Advantages

Built from quality components and hand tested, this Patriot Signature Line memory aims to meet industry standards for compatibility and stability. It supports improved system responsiveness under load, requires standard 1.2 V DDR4 power, and is supplied with Patriot's lifetime warranty and customer support for a hassle-free upgrade process.

Suitable for

• Desktop PCs requiring a 288-pin DDR4 DIMM
• Upgrading single-module systems to 16 GB of RAM
• Office work, web browsing and general multitasking
• Entry-level servers and workstation builds compatible with DDR4-2666

Key specifications

• Capacity: 16 GB
• Type: DDR4
• Speed: 2666 MHz
• CAS Latency: 19
• Form factor: 288-pin DIMM
• Voltage: 1.2 V
• Colours: Black, Green
• Manufacturer part number (MPN): PSD416G26662
• EAN: 814914024317
• Weight: 0.022 kg

How to use

Power off the computer and disconnect it from the mains. Open the case according to the manufacturer instructions, locate an empty 288-pin DDR4 DIMM slot and align the notch on the module with the slot key. Firmly press the module into the slot until the retention clips engage. Close the case, reconnect power, and start the system; the memory should be recognized automatically if the motherboard supports DDR4-2666.

Recommendations

Install modules in matched pairs where the motherboard supports dual-channel operation for improved memory bandwidth. Verify motherboard compatibility with DDR4-2666 specifications and update BIOS if required before installing new memory.
