Pulsar AWT468 AC/AC-transformator 230V AC naar 16V/18V AC 4A 68VA DIN-rail

The Pulsar AWT468 is a high-quality AC/AC transformer designed for reliable power supply in security and automation systems. With selectable output voltage (16V AC or 18V AC) and a rated current of 4A (68VA), it provides stable power for CCTV, access control, and alarm systems. The transformer features short circuit and overload protection, ensuring safe operation. It supports DIN rail (TS35) or surface mounting, making it versatile for various installation environments.

Advantages

Selectable output voltage (16V AC or 18V AC) for flexibility; robust protection features (SCP, OLP) enhance system reliability; compact open-frame design with DIN rail mounting option saves space; passive cooling ensures silent operation and long lifespan.

Suitable for

• CCTV systems
• Access control systems
• Alarm systems
• General low-voltage AC power applications

Key specifications

• Input: 230V AC, 50Hz
• Output: 16V AC or 18V AC (selectable), 4A, 68VA
• Number of outputs: 1
• Protection: Short circuit (SCP), overload (OLP)
• Mounting: DIN rail (TS35) or surface mount
• Enclosure: Open frame module
• Operating temperature: -10°C to +40°C
• Operating humidity: 20% to 90% RH (non-condensing)
• Compliance: PN-EN 60950-1, PN-EN 50130-4, PN-EN 61000-6-3
• Connection: Screw terminals

Recommendations

For optimal performance, ensure proper ventilation and avoid exceeding the rated load. Use appropriate cable sizes for screw terminals. Suitable for indoor use only.
