Rackbodem EFB Elektronik 19 inch 1HE uitschuifbare bodems maximale belasting 30 kg

The EFB Elektronik 19" 1U Pull-Out Shelf provides a compact, sturdy platform for storing and accessing equipment in standard 19-inch racks. Constructed from durable metal with a black finish, the shelf fits a 1U space and supports devices and accessories up to a maximum load of 30 kg. With an overall width of 482.6 mm and a depth of 550 mm, the pull-out design allows convenient front access while maintaining stable support for mounted components.

Advantages

The pull-out mechanism enables quick access to equipment without removing devices from the rack, and the metal construction ensures rigidity under load. A slim 1U height preserves valuable rack space, while the black finish matches typical cabinet interiors. The shelf’s specified mounting depth and physical dimensions make it compatible with a wide range of network cabinets and server racks.

Suitable for

• Mounting small servers, switches or patch panels that require front access
• Storing backup drives, power supplies or peripherals inside a rack
• Temporary placement of tools or diagnostic equipment during maintenance
• Organizing audio/video accessories or network testing gear in a rack-mounted setup

Key specifications

• Standard: 19-inch compatibility
• Rack unit height: 1U (44 mm)
• Maximum load capacity: 30 kg
• Width: 482.6 mm
• Depth: 550 mm
• Maximum mounting depth supported: 650 mm
• Material: metal construction
• Colour: black

How to use

Install the shelf into a compatible 19-inch rack by aligning the mounting holes with the rack rails at the desired 1U position and securing it with appropriate rack screws. Slide the pull-out shelf in and out smoothly to access stored items; distribute weight evenly across the shelf and avoid exceeding the 30 kg maximum load. For devices that require cabling, route cables neatly through the rack to prevent strain when the shelf is extended.

Recommendations

Position heavier items toward the rear of the shelf to improve stability, and check that your cabinet’s mounting depth accommodates the shelf’s specified dimensions. Regularly inspect mounting hardware and the pull-out mechanism for wear, and do not overload beyond the rated capacity to maintain safe operation.
