Redragon GC-PS007-1-V2 850W 80 PLUS Bronze ATX niet-modulaire voeding

The Redragon GC-PS007-1-V2 850W is a reliable and efficient power supply unit designed for gaming and high-performance desktop systems. With 80 PLUS Bronze certification, it delivers up to 87% efficiency at typical loads, reducing energy waste and heat generation. The non-modular design ensures stable power delivery with all necessary cables permanently attached, making it a cost-effective choice for builders who don't require custom cable management.

Advantages

This PSU offers a robust 850W continuous output, sufficient for mid-to-high-end gaming rigs with multiple GPUs. Active PFC ensures stable operation under varying input voltages, while comprehensive protection features (OVP, OPP, SCP, UVP, OTP) safeguard your components. The 120mm hydraulic bearing fan provides quiet and reliable cooling, with an MTBF of 100,000 hours for long-term durability.

Suitable for

• Gaming PCs with single or dual graphics cards
• Workstations requiring stable power delivery
• Budget-conscious builds that prioritize reliability

Key specifications

• Total Power: 850W
• 80 PLUS Certification: Bronze
• Form Factor: ATX
• Modularity: Non-Modular
• Fan Size: 120mm
• Fan Bearing: Hydraulic Bearing
• ATX Connector: 1x 20+4 Pin
• EPS/CPU Connector: 1x 4+4 Pin
• PCIe Connector: 4x 6+2 Pin
• SATA Power Connector: 6x
• Molex Power Connector: 3x
• Input Voltage: 100-240V AC
• Input Frequency: 50/60 Hz
• Protection Features: OVP, OPP, SCP, UVP, OTP
• MTBF: 100,000 hours
• Operating Temperature: 0-40°C
• Safety Certifications: CE, FCC, RoHS, TUV, CB

Recommendations

For optimal performance, pair this PSU with a system that draws up to 800W. Ensure proper airflow in your case to maintain cooling efficiency. The non-modular design is ideal for standard ATX cases with ample space for cable routing.
