Rittal adereindhulzen 4050766, 0,75 mm², blauw, 500 stuks, DIN 46228-4

These Rittal wire end ferrules follow the Rittal colour code, making conductor identification quick and reliable in control cabinet wiring. The blue insulation corresponds to a conductor cross-section of 0.75 mm², so you can see at a glance which ferrule fits which wire. Unlike uninsulated ferrules, the polypropylene collar protects the conductor and provides a secure grip during crimping.

Highlights

• Insulated wire end ferrule for fine-stranded conductors
• Conductor cross-section: 0.75 mm²
• Ferrule length: 12 mm
• Colour: blue (Rittal/DIN colour code)
• Material: electrolytic copper, tin-plated
• Insulation: polypropylene (PP)
• Packaging unit: 500 pieces
• Complies with DIN 46228 Part 4

In daily use

These ferrules are designed for crimping onto fine-stranded conductors. The tin-plated copper ensures low contact resistance and corrosion protection, while the PP insulation withstands temperatures from -40 °C to +105 °C. The UL 94 V-2 flammability rating means the insulation is self-extinguishing. With a voltage rating of 300 V, they are suitable for typical control circuit applications.

Full specifications

• Product type: Wire end ferrule
• Connection type: Crimp
• Conductor cross-section: 0.75 mm²
• Ferrule length: 12 mm
• Colour: Blue
• Material: Electrolytic copper (E-Cu), tin-plated
• Insulation material: Polypropylene (PP)
• Standard compliance: DIN 46228 Part 4
• Temperature range: -40 °C to +105 °C
• Flammability rating: UL 94 V-2
• Packaging unit: 500 pieces
• Voltage rating: 300 V
• Application: For fine-stranded conductors
• RoHS compliant: Yes
• Halogen-free: Yes

Final note

Rittal's colour-coded system reduces wiring errors and speeds up assembly in industrial control panels.
