Rutenbeck patchpanel PP-Cat.6A 24-poorts afgeschermd 1U 23611116

High-density network installations demand reliable cable management and consistent performance. The Rutenbeck Patch Panel PP-Cat.6A provides 24 shielded RJ45 ports in a compact 1U form factor, enabling efficient patching for Category 6A networks.

Who is it for

This patch panel suits IT professionals and network installers building or upgrading data centers, server rooms, and enterprise cabling systems that require 10 Gigabit Ethernet over copper with full shielding.

Main features

• 24 fully shielded RJ45 ports for Cat.6A (Class EA) performance up to 500 MHz
• 19-inch rack mount, 1U height, with rear LSA+ (IDC) termination
• Gold-plated contacts (50µm) for reliable, long-lasting connections
• Supports T568A and T568B wiring schemes with color-coded labels
• Grounding bolt included for proper shield bonding
• Compatible with solid and stranded cables AWG 22-24
• PoE+ (IEEE 802.3at) ready

Specifications

• Product type: Network Patch Panel
• Performance: Cat.6A (Class EA)
• Ports: 24
• Rack units: 1U
• Shielding: Fully shielded (FTP/STP)
• Connector front: RJ45
• Connector rear: LSA+ (IDC)
• Transmission frequency: up to 500 MHz
• Wiring: T568A / T568B
• Housing material: Steel sheet
• Colour: Light grey (RAL 7035)
• Contact plating: Gold (50µm)
• Cable compatibility: AWG 22-24, solid and stranded
• Mating cycles: >750
• Operating temperature: -10°C to +50°C
• Standards: ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.2

Tips

Use a punch-down tool with the correct LSA+ blade for secure terminations. Ensure the grounding bolt is connected to the rack's earth to maintain shielding effectiveness.
