SCHROFF MultipacPRO 3U 84HP 460mm subrack Basic Kit 20860222

Housing PCBs and electronic modules in a 19-inch rack often means choosing between flimsy generic frames or overpriced pre-assembled enclosures. The SCHROFF MultipacPRO 3U 84HP 460mm Subrack Basic Kit solves this by giving you a robust, fully compliant aluminum frame that you assemble in minutes—no special tools needed. It provides a stable, shielded platform for your electronics while keeping costs predictable.

Who is it for

This kit is ideal for system integrators, test engineers, and OEMs who need a reliable 19-inch subrack for prototyping or small production runs. It suits applications in industrial control, measurement, telecommunications, and audio/video where standard IEC 60297-3-101 compatibility is required.

Main features

• 3U height, 84 HP usable width, 460 mm depth—fits standard 19-inch racks
• Unassembled kit includes side panels, front/rear profiles, cover plates, mounting rails, and all assembly hardware
• Aluminum profiles and side panels for lightweight strength; steel cover plates for EMI shielding
• Natural aluminum finish on profiles, light grey RAL 7035 cover plates for a professional look
• Compliant with IEC 60297-3-101 for guaranteed dimensional compatibility

Specifications

• Brand: SCHROFF
• Model: MultipacPRO
• MPN: 20860222
• EAN: 4036088027734
• Product type: Subrack Basic Kit
• Rack height: 3U
• Depth: 460 mm
• Rack width compatibility: 19-inch
• Usable width: 84 HP
• Material (side panels): Aluminum
• Material (profiles): Aluminum
• Material (cover plates): Steel
• Colour (profiles): Natural Aluminum
• Colour (cover plates): RAL 7035 Light Grey
• Standard compliance: IEC 60297-3-101
• Mounting type: Rack Mount
• Application: Housing for PCBs and Electronic Modules
• Included components: 2 side panels, 2 front profiles, 2 rear profiles, 2 cover plates, 2 mounting rails, assembly material
• Assembly status: Unassembled Kit

Tips

For best results, use a torque screwdriver when fastening the aluminum profiles to avoid stripping threads. If you need additional EMC shielding, consider adding SCHROFF gasket kits or conductive front panels. The 84 HP width accommodates standard 3U Eurocard boards with room for cable management.
