SFP-transceivermodule BlueOptics 222904-001-BO 1250 Mbit/s glasvezel

The BlueOptics 222904-001-BO is an SFP fiber optic transceiver module designed for single-port network links with a maximum data transfer rate of 1250 Mbit/s. The module follows the SFP form factor and is finished in silver, providing compact connectivity for switches, routers and media converters requiring a standard SFP interface. Built and certified to common regulatory standards, this transceiver supports reliable optical link deployments and offers a high mean time between failures (MTBF) to suit continuous operation.

Advantages

The transceiver provides a standardized SFP interface that enables hot-pluggable installation and easy replacement in compatible networking equipment. With a rated maximum data transfer rate of 1250 Mbit/s and an MTBF of 1,000,000 hours, the module is designed for stable performance in typical fiber optic links. Compliance with CE, FCC and RoHS standards ensures conformity with common safety, electromagnetic and environmental regulations. The compact, lightweight (0.02 kg) silver housing simplifies handling and integration into dense rack or field installations.

Suitable for

• Single-port fiber links in switches and routers
• Media converters and small form-factor networking equipment
• Replacement or spares for SFP-capable devices
• Short- to medium-distance optical connections where 1250 Mbit/s is adequate

Key specifications

• Form factor: SFP (Small Form-factor Pluggable)
• Maximum data transfer rate: 1250 Mbit/s
• Weight: 0.02 kg
• Color: Silver
• Mean time between failures (MTBF): 1,000,000 hours
• Certifications: CE, FCC, RoHS

How to use

Install the BlueOptics SFP transceiver into a compatible SFP slot on a switch, router or media converter while the host device is powered according to the equipment manufacturer’s guidance for hot-plugging. Connect the appropriate fiber optic cable to the transceiver’s optical interface, ensuring correct connector type and proper fiber polarity. After physical installation and fiber connection, verify link status through the host device’s management interface and perform any required configuration such as speed or port settings to match the network topology.

Recommendations

Handle the module by its housing and avoid touching the optical connector end-face. Keep dust caps on the optical port when not in use and use appropriate cleaning tools before mating. Verify compatibility with the host device and the required fiber type and connector standard. Follow manufacturer guidelines for operating temperature, insertion/removal procedures and electrostatic discharge precautions.
