SFP-transceivermodule HPE X120 1G LC SX

The HPE X120 1G SFP LC SX transceiver module (JD118B) is a compact fiber-optic network module designed for 1 Gbit/s links. It uses an SFP form factor with an LC connector and is intended for short-range multimode fiber (SX) data networking. The module supports a maximum data transfer rate of 1000 Mbit/s and is suitable for upgrading or expanding switches, routers and other network equipment that accept SFP transceivers.

Advantages

The transceiver provides a standardized SFP interface and LC fiber connector for easy installation and hot-swapping. Its small size and light weight make it compatible with high-density networking equipment, while support for 1 Gbit/s data rates ensures reliable gigabit connectivity over multimode fiber. The module is manufactured by HP Enterprise and carries the MPN JD118B for compatibility checks.

Suitable for

• Short-range multimode fiber connections (SX)
• Upgrading or replacing SFP ports in switches and routers
• Data centre and campus network links requiring 1 Gbit/s

Key specifications

• Interface type: SFP
• Connector: LC (fiber optic)
• Maximum data transfer rate: 1000 Mbit/s
• Dimensions (W×D×H): 55.1 × 15.2 × 11.7 mm
• Weight: 0.02 kg
• Manufacturer: HP Enterprise
• MPN: JD118B
• EAN: 885631249604

How to use

Power down the host port if required by your equipment, insert the HPE X120 SFP module into an empty SFP slot until it seats firmly, and connect the LC-terminated multimode fiber patch cable. Verify link status on the host device and configure interface settings as needed for 1 Gbit/s operation. Follow the network equipment manufacturer’s instructions for hot-swap support and firmware compatibility.

Recommendations

Use multimode fiber cabling appropriate for SX optics and keep fiber connectors clean to maintain signal quality. Check the host device compatibility list for HPE JD118B SFP transceivers before installation.
