Sygonix SY-6872546 Insteekslot 60 mm doornmaat

This Sygonix mortise lock stands out with its 60 mm backset and reversible DIN left/right handing, making it a straightforward retrofit for standard door preparations. The galvanized steel body and forend resist corrosion while the profile cylinder (PZ) preparation accepts common Euro cylinders.

Highlights

• Mortise lock with 60 mm backset and 72 mm center distance
• Reversible handing for DIN left or right doors
• Galvanized steel body and 235 x 20 mm forend
• Latch bolt and deadbolt for secure closure
• Accepts 8 mm square spindle follower

In daily use

The lock body measures 165 mm high and 85 mm deep from the forend, fitting most standard door preparations. The reversible latch simplifies installation on either door swing. A profile cylinder (PZ) is not included, allowing you to match your existing keying system.

Full specifications

• Lock type: Mortise lock
• Backset: 60 mm
• Center distance: 72 mm
• Spindle size: 8 mm square
• Forend length: 235 mm
• Forend width: 20 mm
• Locking mechanism: Profile cylinder (PZ)
• Handing: Reversible (DIN left/right)
• Bolt configuration: Latch bolt and deadbolt
• Material: Steel
• Finish: Galvanized
• Application: Standard doors
• Lock body height: 165 mm
• Lock body depth: 85 mm
• Package contents: 1x Mortise Lock

Final note

A dependable mortise lock for standard door applications, with a corrosion-resistant galvanized finish and reversible handing for flexible installation.
