Telegärtner CAT 6A patchkabel, 1x90° haaks, S/FTP, LSZH, zwart, 3,0 m L00002A0175

In tight spaces behind desks or inside cabinets, a standard straight RJ45 connector often forces a sharp bend in the cable, stressing the connector and reducing reliability. This Telegärtner CAT 6A patch cable solves that with a 90° angled connector on one end, allowing the cable to exit downward or sideways and fit flush against a wall or panel.

Who is it for

Network installers and IT technicians working in high-density patching areas, behind furniture, or in shallow enclosures where space is limited. It suits 10 Gigabit Ethernet links in data centres, offices, and industrial environments.

Main features

• One straight RJ45 connector and one 90° angled RJ45 connector
• CAT 6A performance: up to 10 Gbps and 500 MHz bandwidth
• S/FTP shielding: each pair foiled, overall braid screen for excellent EMI immunity
• LSZH (Low Smoke Zero Halogen) jacket for safer fire behaviour
• Telegärtner MP8 FS500 connector series for reliable mating
• 1:1 straight-through wiring, suitable for Ethernet and PoE applications

Specifications

• Length: 3.0 m
• Colour: Black
• Cable standard: CAT 6A
• Shielding: S/FTP
• Jacket material: LSZH
• Connector type: RJ45 (8P8C) both ends
• Connector orientation: Straight on one end, 90° angled on the other
• Data transfer rate: 10 Gbps
• Bandwidth: 500 MHz
• Conductor material: Copper
• Impedance: 100 Ohm
• Flammability rating: IEC 60332-1

Tips

When routing in a cabinet, orient the angled connector so the cable exits toward the cable manager. For PoE devices, this cable supports high power delivery thanks to its copper conductors and robust shielding.
