VCX GV2 6,0-10A Motorbeveiligingsschakelaar 3P 6-10A thermisch-magnetisch

The VCX GV2 6.0-10A is a high-quality motor circuit breaker designed for reliable protection of motors and electrical installations. With a current adjustment range of 6.0 to 10 A, this 3-pole device offers both thermal overload and magnetic short-circuit protection, ensuring safe operation in industrial environments. It complies with IEC/EN 60947-2 and IEC/EN 60947-4-1 standards, making it suitable for a wide range of applications.

Advantages

This motor circuit breaker provides precise current adjustment, allowing you to set the trip current according to your motor's requirements. Its compact design fits easily on a 35mm DIN rail, saving space in control panels. The rotary knob control ensures easy operation, and the screw terminals provide secure connections. With a high breaking capacity of 15 kA at 400V, it offers excellent protection against short circuits.

Suitable for

• Motor protection in industrial machinery
• Control panels and distribution boards
• Pumps, fans, compressors, and conveyors
• Any application requiring overload and short-circuit protection up to 10 A

Key specifications

• Product Type: Motor Circuit Breaker (MCB)
• Number of Poles: 3P
• Current Adjustment Range: 6.0 - 10 A
• Rated Operational Voltage (Ue): Up to 690V AC
• Rated Insulation Voltage (Ui): 690V
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Thermal Trip Setting Range: 6.0 - 10 A
• Magnetic Trip Current: 130 A (approx. 13 x In)
• Short-Circuit Breaking Capacity (Icu) at 400V: 15 kA
• Control Type: Rotary Knob
• Mounting Type: DIN Rail 35mm
• Terminal Type: Screw Terminals
• Protection Degree (IP): IP20
• Overload Protection: Thermal
• Short-Circuit Protection: Magnetic
• Standards Compliance: IEC/EN 60947-2, IEC/EN 60947-4-1
• Tripping Class: Class 10
• Operating Temperature: -20°C to +60°C
• Auxiliary Contacts: Not included (optional accessories available)

Recommendations

For optimal performance, ensure the circuit breaker is correctly sized for your motor's full load current. Use appropriate cable sizes and torque settings as per the manufacturer's instructions. Regularly inspect the device for signs of wear or damage.
