VIDOS 2IP U210-W unifon IP video-deurstation met 7 inch touchscreen, PoE, wit

The VIDOS 2IP U210-W is a professional IP video door station designed for modern access control and communication. Featuring a 7-inch capacitive touch screen with 1024x600 resolution, it runs on Android 6.0 and supports SIP 2.0 for seamless integration with IP telephony systems. Built-in two-way audio, a microphone, and speaker enable clear communication, while PoE (IEEE 802.3af) simplifies installation by combining power and data over a single Ethernet cable.

Advantages

This door station offers a sleek, surface-mountable design in white, suitable for residential and commercial entrances. The capacitive touch screen provides intuitive operation, and the Android OS allows for future app-based enhancements. With 8 alarm zones and 2 relay outputs, it can control door locks or gates and integrate with security systems. Wi-Fi and Bluetooth add wireless flexibility, and the MicroSD slot supports local recording up to 32GB.

Suitable for

• Apartment buildings and gated communities
• Office entrances and reception areas
• Smart home and building automation projects
• Integration with IP PBX and SIP-based intercom systems

Key specifications

• Display: 7" capacitive touch screen, 1024x600 pixels
• Operating System: Android 6.0
• Network: 10/100 Mbps Ethernet, PoE (IEEE 802.3af)
• Wireless: Wi-Fi 2.4GHz (802.11 b/g/n), Bluetooth
• Audio: Two-way, built-in microphone and speaker
• Protocol: SIP 2.0
• Storage: 8GB eMMC internal, MicroSD up to 32GB
• RAM: 1GB DDR3
• Alarm Inputs: 8 zones
• Relay Outputs: 2 (NO/NC)
• Video Codec: H.264
• Audio Codec: G.711
• Power: PoE or 12V DC
• Mounting: Surface mount
• Colour: White

Recommendations

For optimal performance, use a PoE switch compliant with IEEE 802.3af. The VIDOS 2IP App (available for iOS and Android) enables remote monitoring and communication. Ensure network bandwidth of at least 2 Mbps for smooth video streaming.
