WEIß WHA5045HQ condens- en afvoergasbuis Ø 50mm, TÜV-gecertificeerd, 1m, wit (3021)

Condensing boilers produce acidic condensate that demands a drainage solution resistant to corrosion and high temperatures. The WEIß WHA5045HQ pipe, with its 50 mm outer diameter and 1-meter length, provides a reliable pathway for condensate and flue gas in modern heating systems. Its polypropylene construction withstands acidic condensate and exhaust gases up to 120°C, ensuring long-term integrity. TÜV certified, this pipe meets the rigorous demands of condensing boiler installations.

Who is it for

Heating engineers and installers working on condensing boiler flue and condensate systems who need a durable, certified pipe that handles acidic condensate and high temperatures. It is also suitable for maintenance and repair of existing WEIß WHA systems.

Main features

• Polypropylene (PP) material offers high resistance to acidic condensate and exhaust gases.
• Outer diameter of 50 mm and inner diameter of approximately 46 mm.
• Length of 1000 mm (1 meter) for flexible installation.
• Temperature resistance up to 120°C (T120).
• TÜV certified and CE compliant for safety and quality assurance.
• Plain end connection for push-fit or solvent weld installation.
• Compatible with WEIß WHA flue gas and condensate systems.
• Suitable for horizontal and vertical installation.

Specifications

• Product Type: Condensate & Flue Gas Pipe
• Material: Polypropylene (PP)
• Outer Diameter: 50 mm
• Inner Diameter: Approx. 46 mm
• Length: 1000 mm
• Color: White
• Certification: TÜV Certified, CE Compliant
• Application: Condensate drainage, exhaust gas systems for condensing boilers
• Temperature Resistance: Up to 120°C (T120)
• Chemical Resistance: High resistance to acidic condensate and exhaust gases
• Wall Thickness: Approx. 2.0 mm
• Connection Type: Plain end for push-fit or solvent weld connections
• System Compatibility: Designed for WEIß WHA flue gas and condensate systems
• Standard Compliance: Meets requirements of EN 14471
• Installation Orientation: Suitable for horizontal and vertical installation
• UV Stability: Limited (recommended for indoor or protected outdoor use)
• Fire Resistance Class: B2 (according to DIN 4102-1)
• Pressure Rating: Non-pressure (atmospheric)
• Weight per Meter: Approx. 0.27 kg/m

Tips

For best results, ensure the pipe is installed with proper support and alignment to prevent stress on connections. When cutting to length, use a fine-tooth saw and deburr the edges. Protect the pipe from direct sunlight if used outdoors, as UV stability is limited.
