Wittenberg Antennen LTE GPS WiFi SMA-adapterkabel 5 m Poly-103534

Connect your LTE, GPS, or WiFi antenna to your router or modem with this 5-meter SMA male to SMA male low-loss coaxial cable from Wittenberg Antennen. Ideal for installations where the antenna needs to be placed away from the device, such as on a roof, wall, or outdoor mast, while maintaining signal strength.

Key specifications

• Connector 1: SMA male
• Connector 2: SMA male
• Cable length: 5 m
• Cable type: H 155 low-loss coaxial
• Impedance: 50 Ω
• Frequency range: 0 - 6 GHz (supports LTE, 4G, 5G, GSM, UMTS, GPS, WLAN)
• Attenuation: 0.25 dB/m @ 1 GHz, 0.40 dB/m @ 2.4 GHz, 0.60 dB/m @ 5 GHz
• Jacket material: PVC
• Cable diameter: 5.4 mm
• Shielding: Double shielded (foil + braid)
• Colour: Black

Why choose it

The H 155 cable offers low signal loss, ensuring your antenna performs at its best even over longer distances. The double shielding reduces interference, making it suitable for both indoor and outdoor use. SMA connectors are widely compatible with many LTE, GPS, and WiFi devices.

Ideal use cases

• Connecting outdoor LTE/5G antennas to indoor routers
• Extending GPS antenna cables for better satellite reception
• Linking WiFi antennas to access points or repeaters

Good to know

The cable is black and has a PVC jacket, which provides durability and flexibility. It is designed for 50-ohm systems, matching most wireless communication equipment.
