Zebra 50-16000-255R SATA-stroomsplitterkabel 0,15 m

The Zebra 50-16000-255R is a high-quality internal power splitter cable designed to connect two SATA devices to a single SATA power connector. With a compact length of 0.15 m, it is ideal for tight spaces within a computer chassis, ensuring clean cable management and reliable power delivery.

Advantages

This power splitter cable simplifies internal wiring by allowing two SATA drives to share one power source. Its short length reduces clutter and improves airflow inside the case. The cable supports standard voltages (3.3V, 5V, 12V) and is RoHS compliant, ensuring safe and environmentally friendly operation.

Suitable for

• Connecting SATA hard drives or SSDs to a single SATA power connector
• Desktop PC builds and upgrades where additional SATA power ports are needed
• Server and storage systems requiring efficient internal power distribution

Key specifications

• Connector 1: SATA 15-pin Male
• Connector 2: 2 x SATA 15-pin Female
• Cable Length: 0.15 m
• Cable Type: Power Splitter Cable
• Supported Voltage: 3.3V, 5V, 12V
• Conductor Material: Copper
• Jacket Material: PVC
• Color: Multi-color wires (Red, Yellow, Black) with black jacket
• Data Transfer Support: No (Power only)
• RoHS Compliant: Yes
• Product Type: Internal Power Cable
• Number of Connectors: 3 (1 male, 2 female)
• Connector Plating: Nickel
• Operating Temperature: -20 °C to 85 °C

Recommendations

For optimal performance, ensure that the total power draw of the connected devices does not exceed the capacity of the power supply. This cable is intended for internal use only and should be handled with care to avoid damage to connectors.
