ACT grijze 20 m LSZH U/UTP CAT5e patchkabel met RJ45-aansluitingen IB2020

Connect a workstation, server, or network printer in an office or data center with this 20-meter CAT5e patch cable. The grey LSZH jacket is suitable for areas where low smoke and halogen-free materials are required.

Key specifications

• Length: 20 m
• Category: CAT5e
• Shielding: U/UTP
• Jacket material: LSZH
• Colour: Grey
• Connectors: RJ45 male to RJ45 male
• Data transfer rate: up to 1 Gbps
• Bandwidth: up to 100 MHz
• Conductor material: Copper
• Conductor type: Stranded
• Number of pairs: 4
• Wiring standard: TIA/EIA-568B
• Compatibility: 10BASE-T, 100BASE-TX, 1000BASE-T
• Boot type: Snagless
• Insulation material: HDPE
• Outer diameter: 5.0 - 5.5 mm

Why choose it

This patch cable supports Gigabit Ethernet and is built with stranded copper conductors for flexibility. The snagless boot protects the locking tab during installation.

Ideal use cases

• Connecting computers to network switches
• Linking servers to patch panels
• Extending network connections in structured cabling

Good to know

The LSZH jacket reduces smoke and toxic emissions in case of fire. The cable is unshielded (U/UTP) and designed for indoor use.
