ACT Zwart 0,15 meter U/UTP CAT6A LSZH Slimline patchkabel met RJ45-stekkers 90° haaks links naar recht

ACT Black 0.15m RJ45 Cat6a U/UTP is a slimline CAT6A patch cable with a 3.6 mm diameter and LSZH jacket. The cable features a straight RJ45 connector on one end and a 90° angled left RJ45 connector on the other, 28AWG full copper conductors and 50 µ gold-plated contacts. It meets the ANSI/TIA-568.2-D Cat6a standard and is designed for use in datacenter racks and network cabinets where space and airflow are critical.

Advantages

The slim 3.6 mm diameter and reduced bend radius allow for improved airflow and neater cable management compared with standard 5.9 mm Cat6A cords. The LSZH (Low Smoke Zero Halogen) jacket lowers the risk of toxic gas emissions in case of fire. Full copper 28AWG conductors and 50 µ gold-plated RJ45 contacts provide reliable signal transmission and durable connector performance. The straight-to-90° left connector orientation helps connect devices in tight spaces without compromising bend requirements.

Suitable for

Key specifications

How to use

Connect the straight RJ45 end to the network device or switch and the 90° angled left RJ45 end to the patch panel or device port where space is constrained. Ensure connectors are fully inserted until they click. Avoid exceeding the minimum bend radius near the connector; route the slimline cable along rack pathways or cable management channels for best airflow and strain relief.

Recommendations

Use this 0.15 m slimline CAT6A cable for short, high-density connections in server rooms and network cabinets. Do not bend sharply at the connector; maintain gentle curves to preserve performance. For longer runs, select appropriate cable lengths that comply with Cat6A installation practices.
