Akyga EN2090-6-F eenfasige EMI-netfilter 6 A, 120–250 V AC, 50/60 Hz, 6,3-mm-aansluitingen

The Akyga EN2090-6-F is a single-phase EMI filter designed to protect electronic equipment from electromagnetic interference at currents up to 6 A. It is suitable for automation systems, measuring devices, lighting installations and modern power supply systems where voltage purity is critical. The filter features a robust metal housing and 6.3 mm connectors for fast and secure installation.

Key features

• Effective protection against electromagnetic interference
• Robust metal housing for shielding
• Low leakage current for safe and stable operation
• 6.3 mm connectors for fast and secure installation

Specifications

• Brand: Akyga
• MPN: EN2090-6-F
• Product type: EMI Filter
• Filter type: Anti-interference
• Maximum working current: 6 A
• Leads: 6.3 mm connectors
• Leakage current: 0.39 mA @120 VAC 60 Hz, 0.68 mA @250 VAC 50 Hz
• Number of poles: 2
• Material: Metal
• Temperature range: -25°C to +100°C
• Product size (L x W x H): 86 x 52 x 29 mm
• CE compatibility: Yes
• RoHS compatibility: Yes
• REACH compatibility: Yes
• EAN code: 5901720138989
