ALLNET ALL-S0002024 19 inch 1U vast schap, 20 kg draagvermogen, zwart

The ALLNET ALL-S0002024 is a robust 19-inch 1U fixed shelf designed for mounting non-rackmount equipment in standard server cabinets. Constructed from powder-coated steel in black (RAL 9005), it offers a reliable platform with a maximum load capacity of 20 kg. The shelf features a solid (non-perforated) surface and includes mounting hardware for easy installation.

Advantages

This shelf provides a sturdy and cost-effective solution for organizing equipment within a 19-inch rack. Its fixed design ensures stability, while the included screws and cage nuts simplify setup. The black powder-coated finish offers durability and a professional appearance.

Suitable for

• Mounting non-rackmount devices such as switches, routers, or audio equipment in 19-inch server cabinets
• Creating additional workspace or storage within a rack enclosure
• Data centers, server rooms, and network closets requiring organized equipment placement

Key specifications

• Rack Compatibility: 19-inch
• Rack Units: 1U
• Maximum Load Capacity: 20 kg
• Material: Steel, powder-coated
• Color: Black (RAL 9005)
• Internal Shelf Depth: 400 mm
• Overall Width: 482.6 mm
• Overall Height: 44.45 mm
• Mounting Points: 4-point (front and rear)
• Ventilation: Solid (non-perforated)
• Mounting Hardware: Included (screws and cage nuts)
• Recommended Rack Depth: 450 - 800 mm
• Certifications: RoHS Compliant, EIA-310-D

Recommendations

For optimal performance, ensure your rack depth is within the recommended range. This shelf is ideal for lightweight to medium equipment. Always distribute weight evenly and do not exceed the maximum load capacity.
