AWTOOLS AW24391 4-tons 2-koloms hydraulische hefbrug, 400V 3-fase, CE-gecertificeerd

Lifting heavy vehicles safely and efficiently is a constant challenge in any professional workshop. The AWTOOLS AW24391 2-post hydraulic lift solves this by providing a robust 4000 kg lifting capacity, allowing you to raise cars, vans, and light trucks with confidence. Its surface-mounted design and steel cable synchronization ensure stable, level lifting every time, while automatic mechanical locks keep the load secure at any height.

Who is it for

This lift is ideal for automotive repair shops, tire services, and vehicle inspection stations that need a reliable, high-capacity lifting solution. It is also suitable for serious home mechanics with a 400V three-phase power supply and sufficient ceiling height.

Main features

• 4-ton (4000 kg) lifting capacity for a wide range of vehicles
• 2-post hydraulic system with steel cable synchronization for balanced lifting
• Automatic mechanical safety locks with manual release for secure positioning
• Push-button control for easy operation
• Telescopic front and rear arms to accommodate different vehicle chassis points
• CE certified for safety and quality assurance
• Surface mount installation for flexibility in workshop layout

Specifications

• Lifting capacity: 4000 kg
• Lift type: 2-post hydraulic
• Power supply: 400V / 3 phase / 50Hz
• Motor power: 2.2 kW
• Max lifting height: 1900 mm
• Min lifting height: 100 mm
• Overall height: 2826 mm
• Overall width: 3420 mm
• Width between posts: 2800 mm
• Front arm length (telescopic): 712 - 1050 mm
• Rear arm length (telescopic): 990 - 1462 mm
• Lifting speed: approx. 50 seconds
• Lowering speed: approx. 40 seconds (adjustable)
• Synchronization system: steel cable
• Safety system: automatic mechanical locks, manual release
• Control type: push-button
• Hydraulic oil tank capacity: 10 liters (oil not included)
• Certification: CE
• Installation type: surface mount
• Column material: high-strength steel

Tips

Ensure the floor is level and meets the required concrete specifications before installation. Regularly inspect cables, locks, and hydraulic connections for wear. Use only recommended hydraulic oil and replace it according to the maintenance schedule. Always engage the mechanical locks before working under the vehicle.
