AZO Digital DC-DC boost converter 10-20 VDC naar 48 VDC 300W IP21

The AZO Digital PU-300 is a high-performance DC-DC boost converter designed to step up an input voltage of 10-20 VDC to a stable 48 VDC output. With a continuous output power of 300W and a maximum output current of 6.25A, this converter is ideal for industrial applications requiring reliable voltage conversion. Its metal enclosure and IP21 rating ensure durability and protection in indoor environments.

Advantages

This converter offers high efficiency (>85%) and comprehensive protection features including input overvoltage, output short circuit, overload, and over-temperature protection. The passive convection cooling ensures silent operation and long-term reliability without moving parts.

Suitable for

• Industrial automation systems
• Telecommunications equipment
• Battery-powered systems requiring voltage step-up
• LED lighting installations
• Embedded systems and control panels

Key specifications

• Input Voltage Range: 10 - 20 VDC
• Output Voltage: 48 VDC
• Continuous Output Power: 300 W
• Maximum Output Current: 6.25 A
• Converter Type: DC-DC Boost Converter
• IP Protection Rating: IP21
• Efficiency: >85%
• Cooling Method: Convection (Passive)
• Operating Temperature Range: -25°C to +55°C
• Enclosure Material: Metal

Recommendations

For optimal performance, ensure proper ventilation and avoid exposure to moisture. This converter is non-isolated; verify system grounding requirements before installation.
