BEG BRCK LUXOMAT LC-Click 200 witte bewegingsmelder 200° detectiehoek 91002

The BEG BRCK LUXOMAT LC-Click 200 is a wall-mounted motion detector that delivers a wide 200° detection angle, ensuring comprehensive coverage for automatic lighting control in indoor areas. This broad field of view minimizes blind spots and reduces the number of sensors needed per room, making it an efficient choice for both residential and commercial spaces.

Advantages

With a tangential detection range of up to 12 m and radial range of 8 m, the LC-Click 200 provides reliable presence detection even in larger rooms. Its adjustable twilight threshold (2–2000 lux) prevents unnecessary activation during daylight, while the time delay from 15 seconds to 16 minutes—plus a 1-second pulse mode—offers flexibility for various applications, including staircase lighting timers and building automation systems. The IP54-rated, UV-stabilised polycarbonate housing ensures durability against dust and water splashes, and the device operates in temperatures from -25 °C to +50 °C. With a standby power consumption of only 0.5 W, it contributes to overall energy efficiency.

Suitable for

• Indoor lighting control in hallways, stairwells, and corridors
• Commercial spaces such as offices, restrooms, and storage areas
• Residential applications requiring automatic light switching
• Integration with staircase lighting timers or building automation systems via pulse mode

Key specifications

• Detection angle: 200°
• Detection range: 12 m tangential, 8 m radial
• Mounting type: Wall, recommended height 2.0–2.5 m
• Switching capacity: 2300 W resistive, 300 W LED
• Time setting: 15 s – 16 min, pulse (1 s)
• Twilight setting: 2–2000 lux
• Protection class: IP54
• Operating voltage: 230 V AC, 50 Hz
• Output: Relay (phase switched)
• Colour: White (RAL 9010)
• Material: UV-stabilised polycarbonate
• Operating temperature: -25 °C to +50 °C
• Power consumption: approx. 0.5 W

Recommendations

For optimal performance, install the LC-Click 200 at a height of 2.0–2.5 m in a location free from obstructions. Adjust the twilight and time settings according to the specific lighting needs of the area. In pulse mode, ensure compatibility with external timers or automation systems.
