Berker 47441606 inbouw antenneaansluitdoos B.1/B.3 met klepdeksel, polarwit

In residential living rooms and hotel suites, a single wall plate often needs to feed multiple devices—television, radio, and satellite receiver—without clutter or signal loss. The Berker 47441606 antenna socket solves this by combining three coaxial outputs in one flush-mounted unit, finished in glossy polar white and protected by a hinged cover.

Key specifications

• Product type: Antenna socket (end socket / Stichdose)
• Mounting type: Flush-mounted (Unterputz)
• Socket type: Single/end socket with 3 outputs (TV, Radio, SAT)
• Frequency range TV/Radio: 5 – 862 MHz
• Frequency range SAT: 950 – 2400 MHz
• Insertion loss TV/Radio: approx. 1.5 dB
• Insertion loss SAT: approx. 2.0 dB
• Impedance: 75 Ohm
• Shielding factor: > 80 dB
• DC passage: Yes (for SAT)
• Cover type: Hinged cover (Klappdeckel)
• Material: Thermoplastic, halogen-free
• Colour: Polar white (glossy)
• Design line compatibility: Berker B.1, B.3, B.7, B.X, S.1, K.1, K.5, Q.1, Q.3, R.1, R.3, Arsys, Palazzo, W.1, W.3
• IP rating: IP20
• Connection type: Coaxial (IEC for TV/Radio, F-connector for SAT)
• Number of modules: 1-gang

Why choose it

This antenna socket delivers clean signal distribution with minimal loss, ensuring sharp TV pictures, clear radio reception, and reliable satellite channels. The hinged cover protects the connectors from dust and accidental damage while maintaining a sleek appearance. Its halogen-free thermoplastic construction meets modern safety and environmental standards, and the polar white glossy finish blends seamlessly with Berker's B.1 and B.3 switch ranges.

Ideal use cases

• Connecting a TV, radio, and satellite receiver from a single wall outlet in living rooms or bedrooms.
• Upgrading existing flush-mounted antenna points in residential or commercial buildings.
• Projects requiring a uniform look across Berker B.1/B.3 design lines, including hotels and offices.
• Installations where DC pass-through for satellite multiswitches is needed.

Good to know

The socket is designed for flush mounting in a standard 1-gang box and is compatible with a wide range of Berker cover frames. Installation requires standard coaxial cables with IEC and F connectors. The IP20 rating indicates suitability for indoor dry locations only. Always have installation performed by a qualified electrician.
