Coax-adapter DeLOCK 88796

The DeLOCK 88796 coaxial connector is an adapter designed to connect components in radio frequency systems. It features a male TNC connector on one end and a female TNC connector on the other, providing a compact and lightweight solution for reliable coaxial connections. The unit measures 20 mm in depth and 34.2 mm in height and weighs approximately 20 g; it is supplied in a polybag.

Advantages

The adapter offers stable electrical contact between TNC male and female interfaces while maintaining a small footprint and low weight. Its standardized connectors ensure compatibility with equipment that uses TNC coaxial fittings, and the compact dimensions make it suitable for installations with limited space.

Suitable for

Key specifications

How to use

Align the male TNC connector with the corresponding female TNC port and gently screw or push the connector into place according to the equipment's connector type. Ensure connectors are clean and free of debris before mating. Do not apply excessive force; hand-tighten until secure. Verify signal continuity and mechanical stability after installation.

Recommendations

Use the adapter only with compatible TNC interfaces and within the operating limits of your RF equipment. Avoid exposing the connector to moisture or corrosive environments. For best performance, check connections periodically and replace the adapter if wear or damage is observed.
