DeLOCK DisplayPort 1.4 kabel 8K 30 Hz stekker naar bus 1 m paneelmontage zwart

This DeLOCK DisplayPort 1.4 cable extends or relocates a DisplayPort connection. It is a 1 m male-to-female cable that supports up to 8K resolution at 30 Hz and is supplied in a polybag. The female DisplayPort connector can be panel-mounted using two screws so the port can be fixed to a cable duct, enclosure or another surface with a suitable opening, providing an accessible DisplayPort connection point.

Advantages

The cable supports DisplayPort 1.4 signals and 8K@30 Hz video, offers a 1 m length suitable for short extensions, and features a panel-mountable female connector that can be secured with two screws. Its black colour and compact 6 mm diameter suit typical AV and IT installations, and the male-to-female configuration allows easy connection between devices and displays.

Suitable for

• Extending a DisplayPort connection behind desks or cabinets
• Installing a fixed DisplayPort outlet in a rack, panel or enclosure
• Connecting monitors, graphics cards or docking stations with DisplayPort interfaces
• Short cable runs in AV installations requiring panel-mounted ports

Key specifications

• Brand: DELOCK
• Model / MPN: 87825
• EAN: 4043619878253
• Connector 1: DisplayPort (male)
• Connector 2: DisplayPort (female, panel-mountable with two screws)
• Standard: DisplayPort 1.4
• Supported resolution: up to 8K @ 30 Hz
• Cable length: 1 m
• Colour: Black
• Packaging: polybag

How to use

Insert the male DisplayPort plug into the source device (for example a graphics card or docking station) and route the cable to the desired panel or enclosure opening. Secure the female connector to the panel or enclosure using the two mounting screws so the port remains fixed and accessible. Then connect the monitor or target display to the panel-mounted female DisplayPort connector.

Recommendations

For reliable 8K@30 Hz performance, use compatible DisplayPort 1.4 source and display devices and keep the total cable run within recommended lengths. Tighten the mounting screws securely but avoid over-torquing. Store the cable in a dry environment and avoid sharp bends near the connectors.
