Delock Easy 45 module RCA bus naar RCA bus geel / wit 91814

Extending composite video and stereo audio connections through walls, patch panels, or faceplates can be a challenge without a clean, reliable coupler. The Delock Easy 45 Module provides a snap-in solution for joining RCA cables with female connectors on both sides, featuring yellow and white ports for video and left audio channel respectively. This module fits into standard Easy 45 frames, patch panels, and surface mount boxes, enabling neat and accessible A/V connections in residential or commercial installations.

Who is it for

This module is ideal for installers, integrators, and DIY enthusiasts who need to create a permanent, wall-mounted RCA extension point for analog composite video and stereo audio signals. It suits home theater setups, conference rooms, educational facilities, and any environment where RCA cables must pass through a wall plate or patch panel without dangling cables.

Main features

• Female RCA to female RCA coupler for extending composite video (yellow) and left audio (white) connections.
• Snap-in mounting compatible with Delock Easy 45 frames, patch panels, face plates, and surface mount boxes.
• Compact 45 x 22.5 mm module size, standard for Easy 45 systems.
• Plastic housing in white, with color-coded connectors (yellow and white) for easy identification.
• Supports analog audio and composite video signals.

Specifications

• Connector type (input): RCA female
• Connector type (output): RCA female
• Number of connectors: 2 (yellow, white)
• Connector colors: Yellow, white
• Module standard: Delock Easy 45
• Mounting type: Snap-in
• Application: Audio / video extension
• Housing material: Plastic
• Module color: White
• Connector gender: Female to female
• Signal compatibility: Analog audio, composite video
• Module dimensions (H x W x D): 45 x 22.5 x 38 mm
• Weight: 15 g
• Product type: A/V coupler module
• Compatibility: Easy 45 frames, patch panels, face plates, surface mount boxes

Tips

For a complete installation, pair this module with a Delock Easy 45 frame and a suitable wall box. Ensure that the RCA cables are properly seated to avoid signal loss. The yellow connector is typically used for composite video, while the white connector is for the left audio channel in stereo setups; for mono audio, either connector can be used.
