DIGITUS CAT 6A F-FTP Slim patchkabel, koper, LSZH, 0,5 m, grijs

The DIGITUS CAT 6A F-FTP Slim Patch Cable is a high-performance network cable designed for 10 Gigabit Ethernet applications. With its slim design and LSZH jacket, it is ideal for high-density environments where space and safety are critical.

Advantages

This cable offers excellent shielding against electromagnetic interference thanks to its F-FTP (Foiled-Foiled Twisted Pair) construction. The slim 3.8 mm diameter allows for easy routing in tight spaces, while the snagless molded boots protect the RJ45 connectors during installation. The LSZH jacket ensures low smoke and zero halogen emissions, making it safe for use in public and commercial buildings.

Suitable for

• Data centers and server rooms
• Enterprise network installations
• High-speed 10GBase-T networks
• Patch panels and network switches

Key specifications

• Category: Cat 6A (Class EA)
• Shielding: F-FTP (PiMF)
• Conductor: Copper (Cu), AWG 28/7 stranded
• Jacket: LSZH (Low Smoke Zero Halogen)
• Length: 0.5 m
• Color: Grey
• Connectors: RJ45 Male to RJ45 Male, gold-plated (50 µm)
• Wiring: TIA/EIA 568B
• Bandwidth: 500 MHz
• Data transfer rate: 10 Gbps
• Cable diameter: approx. 3.8 mm
• Boot type: Molded, snagless
• Flame retardancy: IEC 60332-1
• Halogen-free: Yes (IEC 60754-2)
• Low smoke: Yes (IEC 61034)
• Operating temperature: -20°C to +60°C

Recommendations

For optimal performance in high-speed networks, pair this cable with compatible Cat 6A components. Ensure proper installation to maintain shielding effectiveness.
