DSIT CAT6 S/FTP netwerk-installatiekabel met massieve geleider, 305m, grijs

CAT6 network installation cable with S/FTP shielding delivers exceptional protection against electromagnetic interference and crosstalk, ensuring reliable Gigabit Ethernet connectivity over long distances. Individually foil-shielded pairs (PiMF) plus an overall braided screen provide superior noise immunity and signal integrity for permanent link installations in demanding environments.

Advantages

Solid bare copper conductors (AWG 23) offer low attenuation and stable performance up to 250 MHz, supporting 1000BASE-T and Power over Ethernet (PoE, PoE+, PoE++). The robust PVC jacket protects against physical wear, while the 305-meter pull box allows for efficient installation with minimal waste.

Suitable for

• Structured cabling systems in office buildings and data centers
• Permanent link installations requiring high bandwidth and reliability
• PoE applications such as IP cameras, wireless access points, and VoIP phones
• Industrial environments with high electromagnetic interference

Key specifications

• Category: CAT6
• Shielding: S/FTP (Screened/Foiled Twisted Pair, PiMF)
• Conductor: Solid bare copper, AWG 23
• Number of pairs: 4
• Length: 305 meters
• Jacket: PVC, grey
• Bandwidth: 250 MHz
• Data rate: Up to 1 Gbps (1000BASE-T)
• Impedance: 100 Ohm
• Standards: TIA/EIA-568-C.2, ISO/IEC 11801
• PoE support: PoE, PoE+, PoE++

Recommendations

For best performance, pair this cable with CAT6 shielded connectors and patch panels.
