Finisar FTL4C1QL2C compatibele BlueOptics QSFP28 100GBASE-LR4 10km Duplex LC transceiver BO25K13602D

The BlueOptics BO25K13602D is a high-performance QSFP28 transceiver designed for 100 Gigabit Ethernet applications. It is fully compatible with Finisar FTL4C1QL2C and offers reliable connectivity for data center and enterprise networks.

Advantages

This transceiver delivers 100G connectivity over single-mode fiber at distances up to 10 km, with low power consumption under 4.5 W. It supports Digital Diagnostic Monitoring (DDM/DOM) for real-time performance monitoring and is hot-pluggable for easy installation.

Suitable for

• 100GBASE-LR4 Ethernet networks
• Data center interconnects
• Enterprise network uplinks
• Telecommunications infrastructure

Key specifications

• Form Factor: QSFP28
• Data Rate: 100 Gbps
• Protocol: 100GBASE-LR4
• Max Distance: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector: Duplex LC
• Wavelengths: 1295.56 nm, 1300.05 nm, 1304.58 nm, 1309.14 nm (LAN WDM)
• Power Consumption: < 4.5 W
• Operating Temperature: 0°C to 70°C
• Compliance: IEEE 802.3ba, SFF-8665, SFF-8636

Recommendations

Ensure your switch or router supports QSFP28 100GBASE-LR4 modules and has a compatible interface. For optimal performance, use with single-mode fiber patch cables with LC connectors.
