GoodConnections Alcasa GC-N0118 Cat.6a afgeschermde Keystone-module, gereedschapsloos, RJ45, 10G, zwart

When a standard Cat.6 keystone won't carry 10 Gigabit traffic reliably, the Alcasa GC-N0118 steps up with full Cat.6a (Class EA) performance in a compact shielded module. Its steel housing and gold-plated contacts keep crosstalk and EMI out of high-density patch panels, while tool-free IDC termination cuts installation time to seconds—no punch-down tool required.

Highlights

• Cat.6a / Class EA performance up to 500 MHz, certified for 10GBASE-T Ethernet
• Tool-free IDC termination with color-coded T568A/B wiring for fast, reliable connections
• Shielded steel housing with gold-plated contacts for superior EMI protection and durability
• Accepts 22–26 AWG solid or stranded conductors, straight 180° cable entry
• Compatible with all standard keystone patch panels, wall plates, and surface boxes

In daily use

This module is built for high-speed backbone links, data centers, and office networks where 10 Gigabit Ethernet is non-negotiable. The tool-free termination means you can terminate a cable in under a minute, even in cramped spaces. The shielded design prevents alien crosstalk in bundles, while the robust steel body withstands repeated insertions and harsh environments. Whether you're upgrading an existing installation or building new, the GC-N0118 delivers consistent, error-free performance.

Full specifications

• Connector type: RJ45 female, 1 port
• Category: Cat.6a (Class EA), shielded (FTP/STP)
• Data rate: 10 Gigabit Ethernet (10GBASE-T)
• Frequency bandwidth: 500 MHz
• Wiring: T568A and T568B, color-coded
• Termination: Tool-free IDC, 22–26 AWG solid/stranded
• Housing material: Steel
• Contact plating: Gold-plated (50µ)
• Cable entry: 180° (straight)
• Durability: >750 mating cycles
• Insulation resistance: >500 MΩ
• Standards: ISO/IEC 11801, EN 50173, ANSI/TIA-568-C.2
• Colour: Black

Final note

For installers who need a dependable, high-speed Cat.6a termination without the hassle of punch-down tools, the GoodConnections Alcasa GC-N0118 is the smart choice. Its shielded steel construction and gold contacts ensure your 10G network runs at full speed for years.
