HAGER WDN2040 universele drukschakelaar-dimmerinzet, inbouw, 1-voudig, 230V, 20-400W

The HAGER WDN2040 is a universal push-button dimmer insert for flush-mounted installation, engineered for automatic load detection and smooth dimming of resistive, inductive, and capacitive loads. It delivers precise brightness control for incandescent, halogen, and dimmable LED/CFL lighting, with a power range of 20-400W for resistive loads and 20-100VA for LED/CFL.

Advantages

Automatic load detection eliminates the need for manual configuration, while soft start and memory function enhance comfort and extend lamp life. Integrated overload, short-circuit, and thermal protection ensure safe operation. The dimmer is compatible with Hager switch ranges and requires a central plate and frame (not included).

Suitable for

• Resistive loads (incandescent, halogen)
• Inductive loads (low-voltage halogen with electronic transformer)
• Capacitive loads (dimmable LED/CFL)
• Push-button control in residential and commercial settings

Key specifications

• Type: Universal push-button dimmer insert
• Mounting: Flush-mounted (UP)
• Operating voltage: 230 V AC, 50 Hz
• Power range: 20-400 W (R), 20-100 VA (LED/CFL)
• Control: Push-button
• Connection: Screw terminals
• Material: Thermoplastic
• IP protection class: IP20
• Operating temperature: -5 to +45 °C

Recommendations

For use with Hager central plates and frames. Verify load compatibility and total wattage before installation. Installation by a qualified electrician is recommended.
