HPE Aruba Networking AP-605H RW 2-radio 3-band 2x2 Wi-Fi 6E 1+4 ETH PSE USB hospitality accesspoint

Engineered for the hospitality sector, the HPE Aruba Networking AP-605H RW delivers high-performance Wi-Fi 6E connectivity in a discreet wall-plate form factor. This access point transforms any hotel room or multi-dwelling unit into a high-speed wireless haven, supporting the latest 6 GHz band for reduced interference and enhanced throughput. With integrated Ethernet ports and PoE passthrough, it simplifies in-room networking for both guests and staff.

Highlights

• Wi-Fi 6E (802.11ax) with tri-band operation (2.4 GHz, 5 GHz, 6 GHz)
• Dual-radio 2x2 MIMO design delivers aggregate data rates up to 2.974 Gbps
• 1x 2.5GbE uplink port with PoE-PD (802.3at/bt) and 4x 1GbE downlink ports
• 2x PoE-PSE output ports (802.3af) to power external devices like IP phones or IoT sensors
• Integrated Bluetooth 5.0 BLE and Zigbee for IoT and location-based services
• Wall-plate mounting fits standard junction boxes for clean, unobtrusive installation

In daily use

Guests enjoy seamless roaming and fast connections for streaming, video conferencing, and smart room controls. The AP-605H's compact design mounts flush to the wall, keeping desktops and nightstands clutter-free. IT administrators benefit from flexible management options—Aruba Central, Instant, or controller-based—and robust security with WPA3 and Enhanced Open support. The PoE passthrough ports simplify deployment of additional devices without extra cabling.

Full specifications

• Wi-Fi Standard: Wi-Fi 6E (802.11ax)
• Frequency Band: Tri-band (2.4 GHz, 5 GHz, 6 GHz)
• MIMO Configuration: 2x2:2 on all bands
• Aggregate Peak Data Rate: 2.974 Gbps
• Ethernet Uplink: 1x 2.5 Gigabit Ethernet (PoE-PD)
• Ethernet Downlink: 4x 1 Gigabit Ethernet
• PoE-PSE Output: 2x 802.3af (max 15.4W per port)
• PoE-PD Input: 802.3at (Class 4) or 802.3bt (Class 6)
• USB Port: 1x USB 2.0 Type A Host
• Bluetooth: Bluetooth 5.0 Low Energy
• IoT Radio: Zigbee (802.15.4)
• Antenna Type: Integrated Omni-directional
• Form Factor: Wall-plate Hospitality Access Point
• Management: Aruba Central, Aruba Instant, Controller-based
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Security: WPA3, Enhanced Open, WPA2/WPA3 Mixed Mode
• Maximum Power Consumption: 40.5W (802.3bt)
• Mounting: Single-gang or dual-gang junction box

Final note

Elevate your property's connectivity with the HPE Aruba Networking AP-605H—a future-ready access point that blends performance, security, and aesthetic elegance. Perfect for hotels, MDUs, and hospitality environments.
