METZ CONNECT MMT361A115-0001 M12 bus 5-polig A-gecodeerd schroefaansluiting veldmonteerbare connector, recht, IP67, staal

Industrial Ethernet and automation systems often face connection failures due to vibration, moisture, or improper cable termination. The METZ CONNECT MMT361A115-0001 solves this by providing a robust, field-attachable M12 connector that ensures a secure, IP67-rated connection for sensors and actuators.

Who is it for

This connector is ideal for maintenance technicians, system integrators, and machine builders who need to create custom-length M12 cables on-site without specialized tooling. It suits industrial automation, robotics, and harsh-environment applications where reliable signal integrity is critical.

Main features

• M12 female connector with 5-pin A-coded configuration for standard sensor/actuator wiring.
• Screw termination allows quick, tool-free field assembly without crimping.
• Straight orientation and compact design for easy integration into cable assemblies.
• IP67 protection when mated, ensuring resistance to dust and temporary immersion.
• Durable zinc die-cast nickel-plated housing and gold-plated contacts for long-term reliability.

Specifications

• Connector type: M12
• Gender: Female
• Number of positions: 5-pin
• Coding: A-coded
• Termination type: Screw termination
• Mounting type: Cable mount (field-attachable)
• Orientation: Straight
• Shielding: Unshielded
• Rated voltage: 60 V
• Rated current: 4 A
• Ingress protection: IP67 (when mated)
• Housing material: Zinc die-cast, nickel-plated
• Contact material: Copper alloy, gold-plated
• Operating temperature range: -40 °C to +85 °C
• Cable diameter range: 4 - 6 mm
• Colour: Steel / Silver
• Pack quantity: 1 piece

Tips

For optimal performance, ensure the cable diameter is within 4-6 mm and strip the wires to the recommended length before screw termination. Always verify the mating connector is also A-coded and 5-pin to avoid misalignment.
