MINIS FORUM UM760 Slim mini-pc AMD Ryzen 5 7640HS barebone

The MINIS FORUM UM760 Slim is a compact and powerful mini PC designed for users who demand high performance in a small footprint. Powered by the AMD Ryzen 5 7640HS processor with 6 cores and 12 threads, it delivers exceptional computing power for productivity, content creation, and light gaming. The integrated AMD Radeon 760M graphics (RDNA 3 architecture) provides smooth visuals and supports up to three displays via HDMI 2.1, DisplayPort 1.4, and USB4 with DP Alt Mode.

Advantages

This barebone system allows you to customize RAM and storage to your exact needs, reducing cost and e-waste. With dual DDR5 SO-DIMM slots supporting up to 64GB and dual storage options (M.2 PCIe 4.0 and 2.5" SATA), you can achieve lightning-fast load times and ample capacity. The slim design saves desk space while offering robust connectivity including 2.5 Gigabit Ethernet, Wi-Fi 6E, Bluetooth 5.2, and multiple USB ports.

Suitable for

• Home office and business productivity
• Media streaming and light content creation
• Compact workstation for software development
• Digital signage and kiosk applications

Key specifications

• Processor: AMD Ryzen 5 7640HS (6 cores, 12 threads, up to 5.0 GHz)
• Graphics: AMD Radeon 760M (RDNA 3)
• Memory: 2x DDR5 SO-DIMM slots, up to 64GB (not included)
• Storage: 1x M.2 2280 PCIe 4.0, 1x 2.5" SATA (not included)
• Video Outputs: 1x HDMI 2.1, 1x DisplayPort 1.4, 1x USB4 (DP Alt Mode)
• USB Ports: 2x USB 3.2 Gen2 Type-A, 2x USB 2.0 Type-A, 1x USB4 Type-C
• Network: 2.5 Gigabit Ethernet, Wi-Fi 6E, Bluetooth 5.2
• Audio: 3.5mm combo jack
• Power: DC 19V external adapter
• Form Factor: Slim Mini PC

Recommendations

For optimal performance, pair with DDR5-5600MHz RAM and a fast NVMe SSD. This barebone is ideal for users who already have compatible components or want to build a custom configuration.
