MITON MT-P205W opbouw verbindingsdoos wit IP44 8 kabelinvoeren

The MITON MT-P205W is a high-quality surface mounting box designed for indoor electrical installations. Made from durable ABS plastic with a sleek white finish, it offers reliable protection for connections and terminations. With an IP44 rating, it provides protection against dust ingress and water splashes, making it suitable for demanding environments.

Advantages

This junction box features a snap-on lid for quick and secure closure, flexible membrane grommets for easy cable entry, and a self-extinguishing halogen-free material for enhanced safety. Its compact dimensions (80x80x40 mm) allow for discreet installation in tight spaces.

Suitable for

• Indoor electrical junction and connection points
• Surface-mounted wiring in residential and commercial buildings
• Installations requiring IP44 protection against dust and moisture

Key specifications

• Brand: MITON
• Model: MT-P205W
• Mounting Type: Surface-mounted
• Material: ABS Plastic
• Colour: White
• IP Rating: IP44
• Number of Cable Entries: 8
• Cable Entry Type: Flexible membrane grommets
• Lid Fastening: Snap-on
• External Dimensions (L x W x H): 80 x 80 x 40 mm
• Operating Temperature Range: -25°C to +60°C
• Flammability: Self-extinguishing
• Halogen-Free: Yes
• Application: Indoor electrical installations
• Standards Compliance: CE, RoHS

Recommendations

For optimal performance, ensure cables are properly stripped and inserted through the membrane grommets. The box is suitable for use with standard electrical cables and connectors. Always follow local electrical codes and regulations during installation.
