Reely polyacetaal tandwiel module 1,0, 15 tanden, 4 mm boring (SH1015HF)

This precision spur gear is machined from polyacetal (POM), a self-lubricating engineering plastic that delivers low friction and high wear resistance for smooth, quiet power transmission in light mechanical drives. With a module of 1.0 and 15 teeth, it provides a reliable 1:1 or custom gear ratio when paired with compatible gears.

Advantages

Polyacetal offers excellent dimensional stability, high chemical resistance, and good wear resistance, making this gear ideal for continuous operation in model building and robotics. The straight-cut involute tooth profile with a 20° pressure angle ensures efficient meshing and reduced backlash.

Suitable for

• Model building and RC vehicles
• Robotics and servo mechanisms
• Light mechanical drives and prototypes

Key specifications

• Material: Polyacetal (POM)
• Module: 1.0
• Number of teeth: 15
• Bore diameter: 4 mm
• Outer diameter: 17 mm
• Pitch diameter: 15 mm
• Pressure angle: 20°
• Tooth profile: Involute, straight-cut

Recommendations

For best performance, pair with a compatible Reely pinion or gear of the same module. Ensure proper shaft fit and alignment to maximize gear life.
