Relais-module Satel INTEGRA 128

The Satel INTEGRA 128 relay module is an accessory for Satel alarm control panels, intended to expand relay outputs for alarm, automation and access control functions. Designed to work with INTEGRA control units, it supports reliable switching and integrates with additional communication modules to extend system capabilities.

Advantages

The module is compatible with Satel INTEGRA systems and provides additional relay outputs to implement alarm responses and simple automation tasks. Its compact metal enclosure and standard mounting dimensions simplify installation in existing control panel setups. Electrical parameters ensure stable operation within the specified input voltage and current range.

Suitable for

• Expanding relay outputs in Satel INTEGRA alarm systems
• Controlling external devices (sirens, indicators, door strikes) from the control panel
• Integrating simple home automation or access control actions via relay switching

Key specifications

• Brand: SATEL
• Model: INTEGRA 128 relay module
• MPN: 5 905 033 330 092
• EAN: 5905033330092
• Input voltage: 20 V
• Frequency: 50–60 Hz
• Current: 3 A
• Dimensions (W × H): 264 × 134 mm

How to use

Install the relay module inside the alarm control enclosure or in a compatible mounting location following the Satel INTEGRA installation guidelines. Connect the module to the control panel according to the system wiring diagram, ensuring correct power supply (20 V, 50–60 Hz) and observe polarity where required. Configure relay outputs within the control panel software to assign functions such as alarm signaling, device control or timed actions.

Recommendations

Use only with compatible Satel INTEGRA control units and follow the manufacturer’s installation and safety instructions. Verify electrical connections and load ratings of connected devices to avoid exceeding the module’s 3 A current specification.
