STEINEL TS PRO COM1 ANT bewegingsmelder schemerschakelaar, 360° PIR, 12 m bereik, IP54, wit 089139

360° detection coverage with a 12 m diameter reach and a twilight threshold adjustable from 2 to 1000 lux make the STEINEL TS PRO COM1 ANT a precise motion and daylight sensor for ceiling mounting. The passive infrared sensor switches a 2000 W resistive load (1000 W compensated LED/fluorescent) directly at 230 V AC, with a time delay from 5 seconds to 15 minutes.

Overview

The TS PRO COM1 ANT is a ceiling-mounted motion detector and twilight switch in a UV-resistant white plastic housing. It operates on 230 V AC and is rated IP54 for protection against dust and splashing water. The detection zone is a full 360° circle, with a tangential reach of 12 m diameter and a radial reach of 8 m diameter when mounted at the recommended height of 2.8 m (range 2.5–4 m).

What stands out

• Full 360° PIR detection with up to 12 m diameter reach
• Twilight threshold adjustable from 2 to 1000 lux
• Time delay adjustable from 5 seconds to 15 minutes
• Switches up to 2000 W resistive or 1000 W compensated LED/fluorescent loads
• IP54 rated for indoor or sheltered outdoor ceiling mounting

Technical details

• Sensor technology: Passive Infrared (PIR)
• Detection angle: 360°
• Max. reach tangential: 12 m diameter
• Max. reach radial: 8 m diameter
• Recommended mounting height: 2.8 m (2.5–4 m)
• Power supply: 230 V AC, 50/60 Hz
• Max. switching capacity resistive: 2000 W
• Max. switching capacity LED/fluorescent: 1000 W (compensated)
• Time setting: 5 sec – 15 min
• Twilight setting: 2 – 1000 lux
• IP rating: IP54
• Protection class: II
• Operating temperature: -20 to +50 °C
• Material: UV-resistant plastic
• Colour: White

Our verdict

A versatile 360° ceiling sensor with wide adjustment ranges for both light level and time delay, suitable for direct switching of lighting loads up to 2000 W.
