Tannoy OCV 8 hangluidsprekerset (zwart)

The Tannoy OCV 8 is a high-performance coaxial pendant loudspeaker designed for distributed audio applications where premium sound quality and reliable performance are required. This hanging speaker set includes the OCV 8 loudspeaker in a sleek black finish, ideal for use in retail spaces, restaurants, hotels, conference rooms, and other commercial environments. With its 8" coaxial driver and 90° conical dispersion, the OCV 8 delivers clear, intelligible speech and full-range music reproduction.

Advantages

• Exceptional sound clarity with coaxial driver design
• Versatile 70V/100V transformer taps for easy integration into distributed audio systems
• Weather-resistant IP44 rating for indoor and covered outdoor use
• Single-point suspension with integrated steel wire rope simplifies installation
• Durable ABS plastic enclosure ensures long-lasting performance

Suitable for

• Retail stores and shopping malls
• Restaurants, bars, and cafes
• Hotel lobbies and conference rooms
• Educational facilities and lecture halls
• Places of worship
• Covered outdoor areas

Key specifications

• Speaker Type: Coaxial Pendant Loudspeaker
• Low Frequency Driver: 8" (200 mm)
• High Frequency Driver: 1" (25 mm) Coaxial
• Frequency Response (-3 dB): 60 Hz - 20 kHz
• Power Handling (AES): 60 W
• Power Handling (Program): 120 W
• Power Handling (Peak): 240 W
• Nominal Impedance: 8 Ohms
• Transformer Taps (70V): 60 W, 30 W, 15 W, 7.5 W
• Transformer Taps (100V): 60 W, 30 W, 15 W
• Sensitivity (1W/1m): 90 dB SPL
• Maximum SPL (Peak): 114 dB SPL
• Dispersion Angle: 90° Conical
• Crossover Frequency: 2.2 kHz
• Enclosure Material: ABS Plastic
• Connectors: Euroblock (removable locking connector with screw terminals)
• Mounting System: Single point suspension with integrated steel wire rope
• Color: Black
• IP Rating: IP44
• System Configuration: Passive

Recommendations

For optimal performance, pair the Tannoy OCV 8 with a compatible amplifier capable of delivering the required power. Ensure proper suspension and safety cable installation as per local regulations. The OCV 8 is an excellent choice for high-quality background music and paging applications.
