Weidmüller W-serie doorvoerklem, schroefaansluiting, 2,5 mm², 800 V, 24 A, donkerbeige, 2 verdiepingen

The Weidmüller W-Series feed-through terminal block (model 1021580000) is a high-quality, double-level terminal block designed for reliable and secure electrical connections in industrial control panels and junction boxes. With a rated cross-section of 2.5 mm² and a rated voltage of 800 V (IEC), it is suitable for a wide range of applications requiring robust and space-saving wiring solutions.

Advantages

This terminal block offers several key benefits: its screw connection technology ensures a secure and vibration-resistant wire termination. The double-level design allows for efficient use of space on DIN rails, enabling higher density wiring. The Wemid insulation material provides excellent thermal and electrical properties, with a flammability rating of V-0 (UL 94) for enhanced safety. The wide operating temperature range from -50 °C to +120 °C makes it suitable for harsh environments.

Suitable for

• Industrial control cabinets and automation systems
• Power distribution and signal wiring
• Building automation and HVAC controls
• Machine building and plant engineering

Key specifications

• Connection Technology: Screw Connection
• Number of Levels: 2 (Double-Level)
• Number of Connections: 4
• Rated Voltage (IEC): 800 V
• Rated Current (IEC): 24 A
• Rated Cross-Section (IEC): 2.5 mm²
• Wire Size (AWG): 26 - 12 AWG
• Mounting Type: DIN Rail TS 35
• Insulation Material: Wemid
• Color: Dark Beige
• Pollution Degree: 3
• Overvoltage Category: III
• Flammability Rating (UL 94): V-0
• Operating Temperature Range: -50 °C to +120 °C
• Stripping Length: 10 mm
• Tightening Torque: 0.4 - 0.8 Nm
• Approvals: cURus, EAC
• Product Type: Feed-Through Terminal Block
• Series: W-Series
• Number of Potentials: 2

Recommendations

For optimal performance, use with appropriate screwdrivers and follow the recommended tightening torque. Ensure proper stripping length and wire preparation. This terminal block is ideal for new installations or retrofitting existing systems where reliable connections are critical.
