BCS 8MP IP turretcamera BCS-P-TIP18FSR3L3-Ai1 met 3,6mm objectief, 30m IR, AI-functies

The BCS-P-TIP18FSR3L3-Ai1 is a high-performance 8 Megapixel IP turret camera designed for professional surveillance. Featuring a 1/2.8" Progressive Scan CMOS sensor, it delivers crisp 3840x2160 resolution at 20fps. Equipped with a 3.6mm fixed lens (F1.6), 120dB True WDR, and Smart IR up to 30m, it ensures clear imaging day and night. Advanced AI capabilities include Perimeter Protection, SMD Plus, and Face Detection. The camera supports H.265+ compression, built-in microphone, microSD storage up to 256GB, and is powered via 12V DC or PoE (802.3af). With an IP67-rated metal housing, it operates in temperatures from -40°C to +60°C, making it suitable for outdoor use.

Advantages

Exceptional 8MP resolution with True WDR for challenging lighting conditions. AI-driven analytics reduce false alarms. Smart IR adapts intensity to avoid overexposure. H.265+ compression saves bandwidth and storage. Rugged IP67 design ensures reliability in harsh environments.

Suitable for

• Perimeter surveillance of commercial and industrial sites
• Retail stores, warehouses, and parking lots
• Smart city and traffic monitoring
• Residential outdoor security

Key specifications

• Sensor: 1/2.8" Progressive Scan CMOS
• Resolution: 8 MP (3840x2160) @ 20fps
• Lens: 3.6mm fixed, F1.6, H-FOV 87°
• IR Range: Up to 30m (Smart IR)
• WDR: 120dB True WDR
• AI: Perimeter Protection, SMD Plus, Face Detection
• Audio: Built-in microphone
• Storage: microSD slot up to 256GB
• Network: 1x RJ-45 10/100 Base-T
• Power: 12V DC / PoE (802.3af), max 6.5W
• Ingress Protection: IP67
• Housing: Metal
• Operating Temperature: -40°C to +60°C

Recommendations

For optimal performance, use a PoE switch or injector compliant with IEEE 802.3af. Pair with a compatible NVR or VMS for full AI functionality. Ensure proper mounting to achieve the desired field of view.
