BCS-MON7400B-S 7" TFT-LCD-monitor met HDMI, VGA, BNC, zwart

The BCS-MON7400B-S is a professional 7-inch TFT-LCD monitor designed for surveillance and industrial applications. With a native resolution of 800x480, it delivers clear and detailed images. The monitor features multiple video inputs including HDMI, VGA, and BNC, making it versatile for various setups. Built-in speakers and audio inputs/outputs provide complete multimedia functionality.

Advantages

Compact and lightweight design with VESA mounting compatibility for flexible installation. The 3D comb filter and 3D noise reduction enhance image quality, while PIP/PBP functions allow simultaneous viewing of multiple sources. Low power consumption under 8W makes it energy-efficient.

Suitable for

• Security and CCTV monitoring systems
• Industrial control and automation displays
• Portable video monitoring in broadcast or field applications
• Embedded systems requiring a small form factor display

Key specifications

• Display: 7-inch TFT-LCD, 800x480 resolution, 16:9 aspect ratio
• Brightness: 300 cd/m², Contrast Ratio: 500:1
• Viewing Angles: 140° horizontal / 120° vertical
• Video Inputs: 2x BNC (CVBS), 1x VGA
• Audio Inputs: 2x RCA (L/R), Audio Output: 1x RCA (L/R)
• Built-in Speakers: 2x 1W
• Power Supply: DC 12V / 1A, Power Consumption: < 8W
• Mounting: Desktop Stand included
• Housing: Plastic, Color: Black

Recommendations

For optimal performance, use a regulated 12V DC power supply. The monitor is ideal for environments where space is limited but reliable video monitoring is required.
