BCS-SU100/48 5-poorts desktop PoE+ switch, 4 PoE-poorten, 48W budget

Deliver up to 30W per port across four PoE+ ports with a 48W total budget — the BCS-SU100/48 powers IP cameras, VoIP phones, and wireless access points from a single compact metal desktop switch.

Overview

The BCS-SU100/48 is a 5-port desktop switch with 4 PoE+ ports (10/100Mbps) and 1 uplink port. It complies with IEEE 802.3af/at, providing up to 30W per port and a total power budget of 48W. The switch supports a switching capacity of 1 Gbps, a packet forwarding rate of 0.74 Mpps, and a 1K MAC address table. It features jumbo frame support up to 1536 bytes, ESD protection of 6 kV, and surge protection of 4 kV. The metal housing allows desktop or wall-mount installation, and the operating temperature range is -10°C to 55°C.

What stands out

• 4 PoE+ ports with 30W per port and 48W total budget
• Plug-and-play, no configuration needed
• Metal housing for durability and heat dissipation
• Wide operating temperature range for versatile deployment
• ESD and surge protection for reliable operation

Technical details

• Ports: 4 x 10/100Mbps PoE+ RJ45, 1 x 10/100Mbps uplink RJ45
• PoE Standard: IEEE 802.3af/at
• Switching Capacity: 1 Gbps
• Packet Forwarding Rate: 0.74 Mpps
• MAC Address Table: 1K entries
• Jumbo Frame: 1536 bytes
• Power Supply: External DC 52V, 1.15A
• Power Consumption (Device Only): <5 W
• Operating Temperature: -10°C to 55°C
• Storage Temperature: -40°C to 70°C
• Humidity: 10% to 90% non-condensing
• Housing: Metal
• Mounting: Desktop / Wall-mount
• ESD Protection: 6 kV
• Surge Protection: 4 kV

Our verdict

A reliable and compact PoE+ switch for small-scale surveillance and network deployments, offering solid power delivery and robust protection in a durable metal chassis.
