Belden DataTwist 2400 Category 6+ U/UTP netwerkkabel, LSZH, grijs, 305m ring

Network downtime and slow data transfer can cripple a business. The Belden DataTwist 2400 Category 6+ U/UTP cable eliminates these risks by delivering reliable 10GBASE-T performance and Power over Ethernet support in a single, future-proof solution. Its 500 MHz bandwidth and solid copper conductors ensure consistent signal integrity for enterprise networks, data centers, and industrial environments.

Who is it for

Network installers, IT infrastructure managers, and system integrators who need a robust horizontal cabling solution for new installations or upgrades in office buildings, data centers, and campuses. This cable is ideal for converged networks where high data rates and PoE are essential.

Main features

• Category 6+ performance with 500 MHz frequency support
• U/UTP construction reduces crosstalk and interference
• 4 twisted pairs of 23 AWG solid bare copper conductors
• LSZH jacket ensures safety in plenum and open areas
• 305 m reel-in-box for easy handling and installation
• Supports PoE, PoE+, and UPoE for converged networks
• Compliant with ISO/IEC 11801, EN 50173, and TIA/EIA-568-C.2

Specifications

• Cable Type: U/UTP (Unshielded Twisted Pair)
• Category: Category 6+ (Augmented Category 6 Performance)
• Number of Pairs: 4
• Conductor: 23 AWG solid bare copper
• Insulation Material: Polyolefin
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Colour: Grey
• Length: 305 m (1000 ft)
• Nominal Outer Diameter: 6.2 mm
• Impedance: 100 ± 15 Ohm
• Maximum Frequency: 500 MHz
• Operating Temperature: -20°C to +60°C
• Flame Rating: IEC 60332-1-2, IEC 60332-3-24 (Cat. C)
• Voltage Rating: 300 V RMS

Tips

Pair with Belden patch panels and keystone jacks for a complete end-to-end system. For best performance, maintain proper bend radius and avoid exceeding maximum pulling tension during installation.
