Cimco 187218 adereindhuls 1,5 mm² deels geïsoleerd rood 100 stuks

Wire end sleeve for fine-stranded and super fine-stranded conductors. The flared entry simplifies wire insertion, and the tin-plated electrolytic copper sleeve ensures reliable crimping.

Advantages

Partially insulated design with red polypropylene insulation for easy identification. Halogen-free and RoHS compliant.

Suitable for

• Fine-stranded conductors
• Super fine-stranded conductors
• Industrial wiring and control cabinets

Key specifications

• Wire cross-section: 1.5 mm²
• Insulation colour: red
• Pack quantity: 100 pieces
• Sleeve material: electrolytic copper, tin-plated
• Insulation material: polypropylene
• Standard: DIN 46228 Part 4
• Metal sleeve length: 8 mm
• Overall length: 14.5 mm
• Temperature range: -40°C to +105°C
• Voltage rating: up to 600 V

Recommendations

Use with appropriate crimping tools for secure connections. Suitable for professional electrical installations.
