DSIT CAT6a U/UTP 100% koper Ethernet-patchkabel, RJ45, 1m, geel

In a busy office, a network technician connects a workstation to a wall outlet using this DSIT CAT6a patch cable. The yellow jacket makes it easy to identify among other cables, and the 1-meter length keeps the setup tidy without excess slack. The cable's 100% copper conductors ensure reliable signal integrity, while the U/UTP design reduces crosstalk without the need for heavy shielding. It supports 10 Gigabit Ethernet, making it suitable for high-speed data transfers in modern LAN environments.

Key specifications

• Cable type: Ethernet patch cable, CAT6a
• Shielding: U/UTP (unshielded twisted pair)
• Conductor material: 100% copper, 24 AWG stranded
• Length: 1 meter
• Colour: Yellow
• Connectors: RJ45 male to RJ45 male
• Data transfer rate: up to 10 Gbps
• Bandwidth: 500 MHz
• Wiring standard: TIA/EIA-568-B.2-1 (T568B)
• Jacket material: PVC
• Operating temperature: -20°C to 60°C
• Impedance: 100 Ohm
• PoE support: PoE, PoE+, PoE++
• Certifications: RoHS

Why choose it

This cable delivers consistent performance for demanding network applications. The 100% copper conductors provide superior conductivity compared to copper-clad aluminium, reducing signal loss and ensuring stable connections. Its CAT6a rating supports 10GBASE-T, making it future-proof for high-speed networks. The U/UTP construction is lightweight and flexible, ideal for dense cabling areas where shielded cables would be too bulky. The yellow colour aids in cable management and quick identification.

Ideal use cases

• Connecting computers to network switches in office environments
• Linking servers and storage devices in data centres
• Setting up home networks with high-speed internet
• PoE applications such as IP cameras and wireless access points
• Temporary connections for testing and diagnostics

Good to know

The cable is compliant with RoHS standards, ensuring it is free from hazardous substances. It is designed for indoor use and should not be exposed to moisture or extreme temperatures beyond the specified range. The stranded conductors make it more flexible than solid-core cables, suitable for frequent bending and movement. The PVC jacket provides durability and protection against everyday wear. For optimal performance, avoid sharp bends and kinks during installation.
