GoodConnections Alcasa GC-N0133 Cat6a S/UTP 10-Gigabit Ethernet-patchkabel

For high-speed network installations where signal integrity is paramount, the GoodConnections Alcasa GC-N0133 stands out with its Cat6a rating and S/UTP shielding, delivering full 10 Gigabit Ethernet performance up to 500 MHz. Unlike standard Cat6 cables, this patch cable supports 10GBASE-T over longer distances, making it a reliable backbone for demanding data centers, server rooms, and high-performance workstations. The 22/26 AWG stranded conductors provide a balance of flexibility and durability, while the screened overall shield reduces alien crosstalk in dense cable bundles.

Highlights

• Cat6a performance: supports 10 Gigabit Ethernet (10GBASE-T) with a bandwidth of up to 500 MHz
• S/UTP shielding: overall braided screen protects against electromagnetic interference (EMI) and alien crosstalk
• RJ45 male connectors on both ends, wired to TIA/EIA-568B standard
• Backward compatible with Cat6, Cat5e, and Cat5 networks
• Stranded 22/26 AWG conductors for easy routing and reliable connections
• 100 Ohm impedance ensures consistent signal transmission

In daily use

This cable is ideal for connecting servers, switches, and high-end workstations where maximum throughput is required. The screened construction makes it especially suitable for environments with high electromagnetic noise, such as industrial settings or areas with many parallel cables. The robust RJ45 connectors with gold-plated contacts ensure a secure and corrosion-resistant connection, while the flexible jacket allows for neat cable management without kinking.

Full specifications

• Product type: Ethernet patch cable
• Cable category: Cat6a
• Shielding: S/UTP (screened overall, unshielded twisted pairs)
• Conductor gauge: 22/26 AWG
• Maximum data transfer rate: 10 Gbps (10000 Mbit/s)
• Frequency support: up to 500 MHz
• Impedance: 100 Ohm
• Connector type: RJ45 male to RJ45 male
• Wiring standard: TIA/EIA-568B
• Backward compatibility: Cat6, Cat5e, Cat5
• Application: network connectivity

Final note

The GoodConnections Alcasa GC-N0133 is a professional-grade Cat6a patch cable that delivers the speed and reliability required for modern 10G networks, backed by solid construction and shielding performance.
